Home Stackable Battery System 40.96kWh With Integrated 5KW Inverter For Energy Backup
Product Positioning:
Built for European Balcony Solar Projects & Bulk Distribution
This 5.12kWh balcony energy storage system is designed for European residential solar retrofit projects and bulk distribution partners.
Engineered with LiFePO4 battery technology, dual MPPT photovoltaic input, and grid-compliant architecture, the system ensures long-term stability, regulatory compliance, and scalable deployment capability.
Built for professional installers and energy distributors, it supports hybrid charging, remote monitoring, and outdoor installation with IP65 protection.
Key Advantages for B2B Partners
-
6000-cycle LiFePO4 battery system for long service life
-
Dual MPPT input (1000W × 2) for flexible PV configuration
-
Grid-compliant design (VDE-AR-N 4105 / EN50549)
-
IP65-rated enclosure for balcony/outdoor installation
-
WiFi, Bluetooth & RS485 communication
-
OEM / Private Label support available
-
Stable production capacity for bulk orders
Technical parameter
| Category |
Specification |
| Battery Type |
LiFePO4 |
| Rated Energy |
5120Wh (5.12kWh) |
| Rated Voltage |
51.2V |
| Rated Capacity |
100Ah |
| Cycle Life |
6000 Cycles |
| Voltage Range |
44.8–58.4V |
| Max Charge / Discharge Current |
50A / 50A |
| Heating Function |
Supported |
| PV Input Voltage Range |
10–100V |
| Max PV Input Power |
1000W × 2 |
| Max PV Input Current |
16A × 2 |
| Grid Type |
Unidirectional |
| Rated AC Voltage |
230V |
| Rated Frequency |
50Hz |
| Max Continuous Output Power |
2400W |
| Max Output Current |
10.9A |
| Protection Level |
IP65 |
| Operating Temperature |
–20°C to 60°C |
| Humidity |
5–95% (No Condensation) |
| Altitude |
≤2000m |
| Communication |
WiFi, Bluetooth, RS485 |
| Dimensions |
520 × 181 × 715 mm |
| Weight |
60 kg |
| Certifications |
CE, CB, EMC, RoHS 2.0, VDE-AR-N 4105, EN50549, UN38.3 |
Compliance & Market Readiness
This system is certified and compliant for European balcony solar deployment, meeting key grid and safety standards including
VDE-AR-N 4105 and EN50549.
Full certification documents are available for distributors and project contractors upon request.
Commercial Applications
-
Balcony solar retrofit projects
-
Residential distributed storage systems
-
Solar installer product portfolio expansion
-
EU-compliant micro energy storage deployment
-
Long-term residential energy programs
Partnership & Supply Capability
We support long-term cooperation with distributors, OEM clients, and energy project contractors.
For bulk pricing, distributor cooperation, or technical inquiries, contact our sales team directly.
Product Details:
Factory workshop:
|
|
5.12kWh Balcony Solar Energy Storage System for Distributors & OEM Partners Images
|
